US7
-
Available inReverse Cycle (Heating & Cooling)
-
Capacities2.5kW, 3.5kW, 5.0kW
-
RefrigerantR32
The Daikin US7 split system air conditioner is the top of its class. Packed with advanced features that distinguishes itself from every other split system, it provides premium air quality for your home with its humidifying, dehumidifying, ventilating and air purification capabilities that not only have made it a Sensitive Choice approved product by the National Asthma Council of Australia, but was also first to earn a 7-star ‘Super Efficiency’ rating in Australia.
A Sensitive
Smart Choice
learn moreSmart Choice
Approved by the National Asthma Council Australia, Daikin air purifiers and split systems are authorised to display the Sensitive Choice butterfly symbol.
Key Features
It's the unique features of Daikin products that makes us the world leader.
-
R32 Refrigerant
Enables increased energy efficiency and a significant reduction in 'Global Warming Potential Factor' - great for the environmentally conscious.
-
Advanced Humidification
A humidification unit in the outdoor unit draws moisture from outdoor air and distributes this indoors to make you feel warmer and more comfortable.
-
Powerful Dehumidification
Cleverly reduces humidity without changing the indoor temperature by intelligent capacity control and mixing of warmer room air with dehumidified air.
-
Coanda Airflow
Discharge louvres designed to stream air along the ceiling for longer throws and delivering rapid cooling and even temperature distribution.
-
2-Stage Filtration
Outdoor unit removes carbon monoxides via a thermal catalyst. Indoor unit's flash streamer removes formaldehyde and allergens from the air.
-
2-Area Intelligent Eye
An infrared human presence sensor helps prevent cold draughts and enables energy saving operations when the room is unoccupied for 20 minutes.
Daikin US7
Top of its class and packed with advanced technologies, Daikin's US7 split system air conditioner delivers the ultimate comfort with its humidifying, dehumidifying, ventilating and air purification features.
Controllers
Countdown On/Off Timer
Quick and easy means to set up the operations of your unit.
Fresh Air Mode
Your room is ventilated with fresh air from the outside.
Circulaton Airflow
Creates a circulatory airflow motion within the occupied space for even temperature distribution.
Self Cleaning Filter
Automatic self cleaning filter collects and deposits dust into internal dustbox for easy disposal.
Quiet Mode
Operation sound levels are reduced by 2-3dBA for quieter heating and cooling.
Humidity Controls
Six humidity settings available to deliver superior comfort.
Direct Connection
For locations without a Wi-Fi network, the app can wirelessly connect directly to the a wireless LAN adaptor equipped air conditioner, when in range.
Wi-Fi Connection
A LAN equipped air conditioner can easily be joined to a local Wi-Fi network. Once connected, the system can be controlled from any networked Android or iOS device.
Internet Connection
All you need is a permanent internet connection for your Wi-Fi network, and an internet connection for your phone or tablet and you can monitor and control your system from virtually anywhere.
5 Year Warranty
learn more
Daikin's 5-year parts and labour warranty applies to split, multi split and ducted air conditioners purchased and installed in homes across Australia
US7 Technology
Technical Specifications
Available Options:
- System: Reverse Cycle
- Capacities: 2.5kW, 3.5kW, 5.0kW
- Indoor Type: Wall Mounted
- Power Supply: 1 Phase, 220-240, 50Hz
- Refrigerant: R32
| Indoor Unit | FTXZ25NV1B | FTXZ35NV1B | FTXZ50NV1B | |
| Outdoor Unit | RXZ25NV1B | RXZ35NV1B | RXZ50NV1B | |
| Rated Capacity | Cool (kW) | 2.5 | 3.5 | 5.0 |
| Heat (kW) | 3.6 | 5.0 | 6.3 | |
| Capacity Range | Cool (kW) | 0.6-3.9 | 0.6-5.3 | 0.6-5.8 |
| Heat (kW) | 0.6-7.5 | 0.6-9.0 | 0.6-9.4 | |
| Indoor Airflow Rate (H) | Cool (l/s) | 178 | 202 | 250 |
| Heat (l/s) | 195 | 222 | 240 | |
| Indoor Fan Speeds | 5 steps, quiet and automatic | |||
| Energy Label/Star Ratings | Cool | 7 | 5.5 | 3.5 |
| Heat | 7 | 5.5 | 4.5 | |
| Front Panel Colour | White | |||
| Power Supply | 1 phase, 220-240V, 50Hz | |||
| Power Input (Rated) | Cool (kW) | 0.42 | 0.68 | 1.18 |
| Heat (kW) | 0.62 | 0.99 | 1.37 | |
| E.E.R/C.O.P | Cool/Heat | 5.95/5.81 | 5.15/5.05 | 4.24/4.60 |
| A.E.E.R/A.C.O.P | Cool/Heat | 5.90/5.77 | 5.12/5.03 | 4.23/4.59 |
| Dimensions (HxWxD) | Indoor (mm) | 295x798x372 | ||
| Outdoor (mm) | 693x795x300 | |||
| Weight | Indoor (kg) | 15 | 15 | 15 |
| Outdoor (kg) | 50 | 50 | 50 | |
| Compressor Type | Hermetically sealed swing type | |||
| Refrigerant Type | R32 | |||
| Max Pipe Length | (m) | 10 | 10 | 10 |
| Max Level Difference | (m) | 8 | 8 | 8 |
| Pipe Sizes | Liquid (mm) | 6.4 | 6.4 | 6.4 |
| Gas (mm) | 9.5 | 9.5 | 9.5 | |
| Outdoor Operating Range | Cool (°CDB) | -10 to 43 | ||
| Heat (°CWB) | -20 to 18 | |||
| Indoor Sound Level (H/SL) | Cool (dBA) | 38/19 | 42/19 | 47/23 |
| Heat (dBA) | 39/19 | 42/19 | 44/24 | |
| Outdoor Sound Level (H/SL) | Cool (dBA) | 46 | 48 | 49 |
| Heat (dBA) | 46 | 48 | 50 | |
| Outdoor EPA Sound Power Level (H) | Cool (dBA) | 59 | 61 | 63 |
| Heat (dBA) | 59 | 61 | 64 | |
