PREMIUM INVERTER DUCTED

SUPERIOR ENERGY PERFORMANCE

PREMIUM INVERTER DUCTED

  • Available in
    Reverse Cycle (Heating & Cooling)
  • Capacities
    5.1kW, 6.0kW, 7.1kW, 10.0kW, 12.5kW, 14.0kW, 16.0kW, 18.0kW, 20.0kW, 24.0kW
  • Refrigerant
    R410A

Daikin Premium Inverter provides superior comfort in next to no time.

Engineered to deliver remarkable energy performance, design flexibility and R22 retrofit capability, the Premium Inverter Ducted range is perfect for providing discreet air conditioned comfort throughout your entire home.

Warranty info

MEPS
Minimum Energy
Performance Standards
learn more

All Daikin air conditioners exceed MEPS requirements, in line with Daikin’s commitment to providing energy efficient, quiet, simple to use and reliable air conditioning solutions.

Key Features

It's the unique features of Daikin products that makes us the world leader.

  • Australian-Made

    Australian Made

    Indoor units are specifically designed and manufactured to Australian standards to withstand the harsher summer climate.

  • Night Quiet Mode

    Night Quiet Mode

    Reduces the outdoor noise levels during sleeping hours and automatically resumes normal operations in the morning.

  • Wide-Capacity Limit

    Wide Capacity Limit

    Allows continuous operations even on the hottest days of summer, or the coldest days of winter (max ambient temperature in Cooling 46°CDB and Heating -15°CWB).

  • R22-Retrofit Capability

    R22 Retrofit Capability

    Provides a cost effective and convenient upgrade from an existing R22 ducted system whilst retaining the field piping.

  • Inverter Technology

    Inverter Technology

    An inverter system works like the accelerator of a car, gently increasing or decreasing power. They reach the desired temperature quicker and steadily maintain it without fluctuations.

  • Industry Leading

    Industry Leading Energy Performance

    Achieved with a redesigned cross-pass heat exchanger, DC fan motor and improved refrigerant control technology.

5 year
5 Year Warranty
learn more

Daikin's 5-year parts and labour warranty applies to split, multi split and ducted air conditioners purchased and installed in homes across Australia

Technical Specifications

Available Options:

  • System: Reverse Cycle
  • Capacities: 5.1kW, 6.0kW, 7.1kW, 10.0kW, 12.5kW, 14.0kW, 16.0kW, 18.0kW, 20.0kW, 24.0kW
  • Indoor Type: Ducted
  • Power Supply: 1 Phase, 220-240, 50Hz or 3 Phase, 380-415v, 50Hz
  • Refrigerant: R410A
  • Premium Inverter (Single Phase)
  • Premium Inverter (3 Phase)
INDOOR UNIT FDYQ50DV1 FDYQ60DV1 FDYQ71LAV1 FDYQ100LAV1 FDYQ125LAV1 FDYQ140LBV1 FDYQ160LAV1
OUTDOOR UNIT RZQS50AV1 RZQS60AV1 RZQS71AV1 RZQS100AV1 RZQS125AV1 RZQS140AV1 RZQS160AV1
Rated Capacity Cool (kW) 5.1 6.0 7.1 10.0 12.5 14.0 16.0
Heat (kW) 6.0 7.0 7.5 12.5 15.0 16.5 18.0
Capacity Range Cool (kW) 3.2-5.6 3.2-6.0 3.2-8.0 5.0-11.2 5.7-14.0 6.2-15.5 7.3-16.3
Heat (kW) 3.5-7.0 3.5-8.0 3.5-9.0 5.1-12.8 6.0-16.2 6.2-18.0 7.3-18.2
Power Input (Rated) Cool (kW) 1.50 1.71 2.05 2.62 3.68 4.13 4.92
Heat (kW) 1.62 2.09 1.89 3.02 3.79 4.29 4.72
E.E.R./C.O.P. C/H 3.40/3.70 3.51/3.35 3.46/3.96 3.82/4.14 3.40/3.96 3.39/3.85 3.25/3.81
Air Flow Rate (Rated) l/s 370 400 566 814 840 1000 1120
Indoor Sound Level (@1.5m) dBA 44.4 45.2 40.5 43.0 45.0 46.0 48.0
Piping Length m 50 75
Indoor Fan Speeds   H/M/L
Dimensions (HxWxD) Indoor (mm) 300x1015x851 360x1188x869 360x1498x899 430x1498x943
Outdoor (mm) 770x900x320 990x940x320 1430x940x320
Weight (FDYQ) Indoor (kg) 35 35 47 57 61 64
Outdoor (kg) 64 75 108
Weight (FDYQT) Indoor (kg) - - 49 59 63 66
Outdoor (kg) 64 64 75 108
Power Supply V/HZ 1 Phase, 220-240V, 50Hz
Compressor Type   Hermetically Sealed Swing Type Hermetically Sealed Scroll Type
Refrigerant   R410A
Refrigerant Pipe Size Liq (mm) 6.4 (Flared) 9.5 (Flared)
Gas (mm) 12.7 (Flared) 15.9 (Flared)
 Drain (mm) ID 25 / OD 32
Supply Air Opening HxW (mm) 202x762 (Flange) 243x751 (Flange) 243x1152 (Flange) 315x1152 (Flange)
Return Air Opening HxW (mm) 1x400 (Oval) 2x400 (Oval)
Outdoor Operating Range Cool (°CDB) -5 to 46
Heat (°CWB) -15 to 16
Outdoor Sound Level (H) @ 1 metre from front of unit Pressure dBA (C/H) 48/50 50/52 53/55 54/56 57/59
EPA Sound Power Level Outdoor (dBA) 66 69 -



INDOOR UNIT FDYQ100LAV1 FDYQ125LAV1 FDYQ140LBV1 FDYQ160LAV1 FDYQ180LBV1 FDYQ200LBV1 FDYQ250LAV1
OUTDOOR UNIT RZQS100AY1 RZQS125AY1 RZQS140AY1 RZQS160AY1 RZQS180AY1 RZQS200AY1 RZYQ10PUY1
Rated Capacity Cool (kW) 10.0 12.5 14.0 16.0 18.0 20.0 24.0
Heat (kW) 12.5 15.0 16.5 18.0 20.0 22.4 26.8
Capacity Range Cool (kW) 5.0-11.2 5.7-14.0 6.2-15.5 7.3-16.3 10.8-20.0 12.0-22.4 15.0-28.0
Heat (kW) 5.1-12.8 6.0-16.0 6.2-16.2 7.3-18.2 12.0-22.4 13.4-25.0 16.8-31.5
Power Input (Rated) Cool (kW) 2.62 3.68 4.13 5.35 5.64 6.08 7.47
Heat (kW) 3.02 3.79 4.29 5.05 5.84 6.17 8.14
E.E.R./C.O.P. C/H 3.82/4.14 3.40/3.96 3.39/3.85 2.99/3.56 3.19/3.42 3.29/3.63 3.21/3.29
Air Flow Rate (Rated) l/s 814 840 1000 1120 1180 1200 1400
Indoor Sound Level (@1.5m) dBA 43.0 45.0 46.0 48.0 45.5 44.0 49.5
Piping Length   75 100 150
Indoor Fan Speeds   H/M/L
Dimensions (HxWxD) Indoor (mm) 360x1498x899 430x1498x943 500x1230x970 500x1430x970 500x1430x910
Outdoor (mm) 1345x900x320 1430x940x320 1680x930x765 1680x1240x765
Weight (FDYQ) Indoor (kg) 57 61 64 64 78 86 92
Outdoor (kg) 108 192 285
Weight (FDYQT) Indoor (kg) 59 63 66 78 86 92
Outdoor (kg) 108 192 285
Power Supply V/HZ 3 Phase, 380-415V, 50Hz
Compressor Type   Hermetically Sealed Scroll Type
Refrigerant   R410A
Refrigerant Pipe Size Liquid (mm) 9.5 (Flared) 9.5 (Brazed)
Gas (mm) 15.9 (Flared) 19.1(Brazed) 22.2 (Brazed)
Drain (mm) ID 25 / OD 32 BSP 3/4 Inch Internal Thread
Supply Air Opening HxW (mm) 243x1152 (Flange) 315x1152 (Flange) 376x827 (Flange) 376x938 (Flange)
Return Air Opening HxW (mm) 2x400 (Oval) 350x918 (Flange) 350x1118 (Flange)
Outdoor Operating Range Cool (°CDB) -5 to 46 -5 to 43
Heat (°CDB) -15 to 16 -20 to 16
Outdoor Sound Level (H) @ 1 metre from front of unit Pressure dBA (C/H) 53/55 54/56 57/59 57/57 60/60
EPA Sound Power Level Outdoor (dBA) 69 -



Ducted Systems

A Daikin ducted system provides discreet air conditioned comfort throughout your entire home. It can be installed in a new home or tailored to suit an existing one, and once installed, only the controller, the return air and discharge grilles are visible inside your home.

Why choose Daikin?

Experts in Air Conditioning

Experts in Air Conditioning

Specialist Dealer Network

Specialist Dealer Network

Quality After Sales Support

Quality After Sales Support

Sensitive Choice® Approved

Sensitive Choice® Approved

Where to buy Daikin

A Daikin Specialist Dealer will assess, plan and install the right air conditioning solution for you, with creativity and sensitivity to the needs of your family or business.
